Deepcool CG530 WH REVERSE FAN (DC-CG530 WH FAN(Reverse))

The DeepCool CG530 4F WH is a mid-tower ATX case designed for enthusiasts who value both aesthetics and performance. Its pillarless design features tempered glass front and side panels, offering an unobstructed view of your components. The dual-chamber layout separates the PSU and storage devices from the main components, enhancing airflow and cable management. Pre-installed with three 120mm PWM ARGB reverse-flow fans on the side and one 120mm PWM ARGB standard fan at the rear, it ensures efficient cooling and a vibrant lighting display.

SPECIFICATIONS

• Model Number: R-CG530-WHADA4-G-1

• Dimensions: 440 × 285 × 399 mm (L × W × H)

• Net Weight: 7.1 kg

• Materials: ABS, SPCC, Tempered Glass

• Motherboard Support: ITX, Micro-ATX, ATX (including rear connector support)

• Front I/O Ports:

  • 2 × USB 3.0

  • 1 × Gen2 Type-C

  • 1 × Audio/Mic Combo

• Drive Bays:

  • 2 × 3.5"

  • 2 + 1 × 2.5"

• Expansion Slots: 7

• Pre-Installed Fans:

  • Side: 3 × 120mm PWM ARGB Reverse Blade

  • Rear: 1 × 120mm PWM ARGB

• Fan Support:

  • Top: 3 × 120mm or 2 × 140mm

  • Side: 3 × 120mm or 2 × 140mm

  • Rear: 1 × 120mm

  • Bottom: 3 × 120mm (configurable with HDD/SSD mounts)

• Radiator Support:

  • Top: 120/140/240/280/360mm

  • Side: 120/140/240/280mm

  • Bottom: 120/240/360mm

• CPU Cooler Height Limit: 160mm

• GPU Length Limit: 410mm

• Power Supply Type: ATX PS2 (maximum length: 210mm)

• Cable Management Space: 45mm
